4-1419172-4
Manufacturer:
TE Connectivity
Mfr.Part #:
4-1419172-4
Datasheet:
Description:
Relays Through Hole Coil Current:37.5 mA Contact Current Rating:2 A SPDT Coil Voltage (DC):12 V Relay 947 mW
| Parameter | Value |
|---|---|
| Length | 15.3924 mm |
| Width | 10.4 mm |
| Termination | PCB |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Height | 11.5 mm |
| Circuit Type | SPDT (1 Form C) |
| Packaging | Bulk |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Weight | 3.997283 g |
| Contact Plating | Gold |
| Contact Material(Contact Finish) | Gold |
| Max Current Rating | 3 A |
| Lifecycle Status | Production (Last Updated: 4 days ago) |
| ELV | Compliant |
| Throw Configuration | SPDT |
| Coil Voltage (DC) | 12 V |
| Coil Current | 37.5 mA |
| Coil Type | Non-Latching |
| Coil Resistance | 320 Ω |
| Relay Type | Relay |
| Operate Time | 7 ms |
| Release Time | 5 ms |
| Contact Current Rating | 2 A |
| power consumption | 450 mW |
| Termination Style | PC Pin |
| Switching Voltage | 125 VAC, 125 VDC |
| Coil Power | 947 mW |
| Contact Voltage Rating (AC) | 125 V |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 4 days ago) |
| Must Operate Voltage | 8.4 V |
| Must Release Voltage | 1.2 V |
Stock: 326
Distributors
pcbx
pcbxUnit Price$4.88165
Ext.Price$4.88165
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $4.88165 | $4.88165 |
| 10 | $4.66877 | $46.68770 |
| 25 | $4.32423 | $108.10575 |
| 50 | $4.17377 | $208.68850 |
| 100 | $4.01731 | $401.73100 |
| 300 | $3.87102 | $1161.30600 |
| 500 | $3.73006 | $1865.03000 |
| 1000 | $3.59840 | $3598.40000 |
